Inkjet Printing > E500H
E500H
Functions
Selectable Languages: English, Italian, Chinese and other.
Text: 180° text rotation.
Adjustable parameters: Dot size, character width and height. Print delay, Bold from 1 to 9. Date, time, barcode, serial No. and shift group.
Repeat printing automatically.
Bold from 1 to 9 times.
More than 100 messages storage (support BMP format).
Features
- Max speed: 60 mt/min.
- Printable height: from 1 mm to 54 mm by one printhead.
- Print line capability: unlimited.
- Fonts: more than 10 varieties.
- Date format: Variety of date modes available (Production date, Use by Date, Expiration Date, etc).
- Barcodes: Code EAN 8, Code EAN 13, Code ISBN10, Code ISBN 13, Code UPC-A, Code UPC-E, Code 128, Code 128 GSI/UCC, Code 2/5 Interl, Code 2/5 Standard, Code 39, Code bar, Data matrix, PDF 417.
Technical Parameters
- Dimensions:
- – Printhead 126x90x28 mm.
- – Host machine 274x222x100 mm.
- Weight:
- – Housing 2,9 Kg.
- – Printhead 0,63 Kg.
- Power supply: 100V-240V, 50-60Hz, ~18 W.
- Environment requirement: 5-40°C; 10%-90% RH (non condensing).
- Port: USB 2.0, Sensor, Encoder.
- Interface: 7 inch color touchscreen display.
- Ink solutions: Support non porous and porous, food grade ink and anti scrub ink.
- Support various colors ink: Yellow, White, Black, Red, Green, Blue.
- Others: No external compressed air, no solvent.
